VisualTreeSearch

A powerful web agent visualization tool that helps you understand and analyze web automation processes through visual tree search.

🌐 Live Demo

Visit our live demo at: visual-tree-search.pathonai.org

🌟 Features

• Interactive visualization of web agent actions
• Real-time tree search visualization
• Modern and responsive UI
• Comprehensive web automation analysis

🛠️ Tech Stack

Frontend

• Framework: NextJS 14
• Styling: TailwindCSS
• UI Components: Shadcn UI
• Deployment: Vercel

Backend

• Framework: FastAPI
• Deployment: AWS ECS

Browser Service

• Framework: FastAPI
• Deployment: AWS ECS
• Browser Engine: Chromium (via Playwright)

State Reset

• Framework: FastAPI
• Deployment: AWS EC2
• Database Access: SQLAlchemy ORM connecting to MariaDB (using MySQL-compatible interface)

🚀 Getting Started

Prerequisites

• Node.js (Latest LTS version)
• Python 3.8+
• npm or yarn
• Git

Installation

1. Clone the repository

git clone https://github.com/PathOnAI/VisualTreeSearch-Demo.git
cd VisualTreeSearch-Demo

2. Backend Setup

# Navigate to backend directory
cd visual-tree-search-backend

# Create and activate virtual environment (recommended)
python -m venv venv
source venv/bin/activate  # On Windows use: venv\Scripts\activate

# Install dependencies
pip install -r requirements.txt
pip install uvicorn[standard]  # Install uvicorn with standard extras

3. Frontend Setup

# Navigate to frontend directory
cd ../visual-tree-search-app

# Install dependencies
npm install

# Create .env file
echo "NEXT_PUBLIC_BACKEND_URL=http://127.0.0.1:3000" > .env

Local Development

Backend

1. Navigate to backend directory:

cd visual-tree-search-backend

2. Activate virtual environment (if not already activated):

source venv/bin/activate  # On Windows use: venv\Scripts\activate

3. Run the FastAPI server:

uvicorn app.main:app --host 0.0.0.0 --port 3000 --reload

Note: The --reload flag enables auto-reload when code changes are detected. Remove it in production.

Frontend

1. Open a new terminal and navigate to frontend directory:

cd visual-tree-search-app

2. Start the development server:

npm run dev -- -p 3001

The application should now be running at:

• Frontend: http://localhost:3001
• Backend: http://localhost:3000

📝 Project Structure

VisualTreeSearch-Demo/
├── visual-tree-search-app/        # Frontend application
│   ├── src/                      # Source code
│   ├── public/                   # Static files
│   └── package.json             # Frontend dependencies
├── visual-tree-search-backend/    # Backend API service
│   ├── app/                     # Backend source code
│   ├── requirements.txt         # Backend dependencies
│   └── test/                    # Test files
├── visual-tree-search-browser-service/  # Browser automation service
└── visual-tree-search-state-reset/     # State management service
